SUPER HOGSTER A3 2.9-11.6x35mm

Thermal scopes
> SUPER HOGSTER A3 2.9-11.6x35mm

Instruction manual
(ВЕ43345 / BE43345L)

Features

Superior for hogs and predator control at medium- and long-range distances

Picture-in-Picture function- 2X multiplied image on a top of the display
Automatic shatter based thermal VOx core with Auto- or Manual calibration
Switchable image polarity: White Hot / Black Hot / Red Hot / Colored Hot
8 reticle patterns including 3 BDC reticles
4 color options for each reticle pattern
Manual control of the image sharpness and screen brightness
Ability to save 4 profiles of zeroing calibration data
Stradiametric Rangefinder function to estimate the distance to the targets of known size
A precise lens focusing mechanism
Option to power by rechargeable 3.7V accumulators
5V DC external power supply option via a Type C USB port
Blind Pixel repair tool
Standby mode

Digital Compass

Inclinometer
Battery status indicator
Nitrogen purged
Video out
16Gb internal memory
Built-in internal recording function in .mp4 (video) and .jpeg (CAMERAs) formatst
Wi-Fi capable- allows media recording to the mobile device (Super Hogster App is required)
Equipped with a Quick-detach (QD) mount (BE43345) or LaRue Tactical Quick-detach (QD) mount (BE43345L)
4 years warranty




Customer review

Dear Bering Optics, thank you for the nice scope. I have a Super Hogster that I purchased new a year ago and the front lens cap will not stay closed. The little latch part on the cap broke off. Thank you for quickly sending a replacement. PS. I love this scope and have not had any other problems. It has your original scope mount and holds zero really good when switching from gun to gun. Just thought I give you some feed back. I recommend your scopes to everybody. Ernest, Conestoga, USA.

Customer review

Here is a link to a current internet forum thread on the Super Hogster: https://texashuntingforum.com/forum/ubbthreads.php/topics/7982405#Post7982405

About

The Bering Optics SUPER HOGSTER A3 2.9-11.6x35mm Thermal Weapon Sight is designed to appeal to consumers who desire more features and capabilities. The Superb Germanium optics paired with an advanced 12µm Vanadium Oxide (VOx) uncooled thermal core and proprietary electronics are the heart of this powerful LWIR spectral, all-environment system.

SUPER HOGSTER features an intuitive, user-friendly menu to customize settings to the shooter’s needs without disengaging from the target, including BDC and Crosshair reticles along with White, Black, Red, and Colored image polarization. There are a picture-in-picture and zeroing calibration memory functions, digital compass and inclinometer to further enhance the user experience. The sight is exceptionally lightweight, compact and .308 Cal. tested. It comes with a quick-release (QR) mount that makes the mounting on any type of rifle, equipped with the Picatinny rail, quick and easy. The sight compactness makes it suitable for use as a handheld imager for scouting purposes.

The scope is nitrogen-purged, water-resistant, dust- and shock-proof, and is action-ready in any environment or light conditions. SUPER HOGSTER is suitable for use in colder temperatures thanks to the unique built retaining its heat and keeping the cold-sensitive elements warm, virtually making it a great universal choice for any demanding user.

Specifications
Optical Magnification, x

2.9x

Digital Magnification, x

2x or 4x

Objective lens system

35mmF/1.1

Angular FOV at Optical Magnification (Horizontal x Vertical), degrees

H7.5° x V5.7°

Linear FOV at Optical Magnification @ 100yrds/90m (Horizontal x Vertical), yd/m

H13.1 / 11.7 x V10 / 9

Eye relief, mm

40mm

Focus range, yard

1 to infinity

Diopter Adjustment, D

-5; +5

Reticle W/E adjustment value at a distance of 100m, in/cm

0.67”/ 1.71cm increment per pxl

Core resolution, pxl

384x288

Pixel pitch, µm

12

Start-up time, min., sec.

8

Thermal Sensitivity (NETD), mK

<40

Display type and resolution, pxl

LCOS 1280х960

Detection Range, yd (Target size: Running Hog L16 & H19), approx., yd/m

1100 / 1000

Dimensions, in/mm

7.7”x2.83”x2.36” / 195x72x60

Weight without mount and batteries, but with eyepiece and lens cap, oz/g

17.14 / 486

Power supply

3V CR123 (two) or 3.7V rechargeable (two) or 5V DC (USB C-type)

Estimated battery life, hours

3.5 for two 3V CR123

Operating temperature, typical, °F

-14°F to +122°F

Water intrusion

IP67

Humidity, %/°С

up to 96%

In Box
  • SUPER HOGSTER VOx 384x288 12µm Thermal Sight
  • Video-out or external power supply Type C USB cable
  • QD Weapon Mount
  • Two Lithium CR123 batteries
  • Front lens protective cap
  • Eyepiece rubber eye guard
  • Soft Carrying Case
  • Lens Cleaning Cloth
  • Instructions manual

OPTIONAL ACCESSORIES (sold separately)

  • 35mm Lens Focus Control Collar
  • Hard Carrying Case
